| Brand Name: | JUGE |
| Model Number: | AG8000-NOx |
| MOQ: | 1 Unit |
| Price: | USD3000-5000 |
| Payment Terms: | T/T,Online order |
| Supply Ability: | 100 Unit/Week |
The transmitter supports multi-point upload functionality, enabling multi-point data integration, analysis, reporting, and publishing.
Fast response, with T90 as quick as 10 seconds.
Equipped with passive relay contact output and audible/visual alarm function.
Specially designed anti‑interference sensor solves the problem of sensor poisoning and damage, offering extremely high reliability.
Excellent front‑end pretreatment system that dries and filters the detected gas, ensuring more accurate gas detection, more stable operation, and effectively extending sensor life.
Features historical data storage, allowing alarm data and records to be viewed at any time.
Adopts the standard HJ212 protocol, seamlessly connecting to regional environmental protection platforms.
>>Main technical parameters
| Detect Gas | NO, CO, NOX, O2, temperature |
| Detection Principle | Constant potential electrolysis method (imported sensor) |
| Detection Method | Fixed pump suction online continuous monitoring |
| Range | NO, CO, NOx: 0–500 mg/m³; O₂: 0–25% VOL (optional; ranges not listed can be customized) |
| Resolution | 0.01, 0.1 |
| Indication error |
≤±3.0% F.S. (depends on sensor) |
| Installation | Wall-mounted, floor-standing, pole-mounted |
| Repeatability | ≤±0.5 % F.S. |
| Zero drift | ≤±5% F.S./year |
| Range drift | ≤±5% F.S./year |
| Response time | ≤15S T90 |
| Recovery time | ≤20S |
| Alarm |
Audible and visual alarm, 1 or 2 dry contact signal outputs, adjustable alarm threshold |
| Protection level | Main body IP54, detector IP66 |
| Working temperature | -20℃-+200℃ |
| Working humidity | ≤95%RH |
| Relative humidity | 10-95%RH, Built in full temperature and humidity compensation function |
| Power supply | 220V AC, 40W |
| Working Pressure | ≤200Kpa |
| Data storage | Built in storage capacity, optional storage card |
