| Brand Name: | JUGE |
| Model Number: | AG8000 |
| MOQ: | 1 Unit |
| Price: | USD1000-5000 |
| Payment Terms: | T/T,Online order |
| Supply Ability: | 100 Unit/Week |
Equipped with a professional pretreatment system that effectively purifies the sample gas, ensuring that the gas entering the analyzer contains no impurities that could interfere with measurement, thereby guaranteeing measurement accuracy.
Utilizes internationally advanced sensors, giving the system a longer service life and stronger anti-interference capability, capable of monitoring multiple gases simultaneously to ensure data accuracy.
The built-in detector supports 4-20mA and RS485 output signals, and can be configured with DTU, display screen, etc., for data upload to the platform.
Built-in automatic heat dissipation system effectively extends the equipment's service life.
Available in standard and explosion-proof versions according to explosion-proof requirements.
>>Main technical parameters
| Detected Gases | Combustible gas, oxygen, flue gas, exhaust emissions, toxic and hazardous VOCs, etc. |
| Detection Principle | Electrochemical, infrared, PID photoionization (principle varies by gas); other gases support customization |
| Detection Method | Pump suction |
| Display Method | 7-inch LCD color screen |
| Display Units | ppm, mg/m³ |
| Measurement Range | 0–200 mg/m³ (optional; ranges not listed can be customized) |
| Resolution | 0.1 mg/m³ |
| Accuracy | ≤3% FS |
| Operation Method | Touch operation |
| Warm-up Time | ≤90 seconds |
| Response Time | T90 ≤90 seconds |
| Output Signal | GPRS, 4–20 mA, RS485 |
| Operating Humidity | ≤95% RH, non-condensing |
| Operating Temperature | -40°C ~ +60°C |
| Power Supply Voltage | AC220V, 50Hz ±1% |
| Operating Pressure | 86–106 kPa |
| Installation Method | Wall-mounted, pole-mounted |
| Protection Rating | IP54 |
